Hudson Reed Tec Lever Mono Basin Mixer Tap with Basin Waste

Ease of use without compromising on design. Swivel spout. Ceramic disc technology for long life and smooth operation. High quality brass internals with luxury chrome finish. WRAS approved (not including waste).

Technical Specification

Height: 217 mm

Weight: 2.42 kg

Width: 260 mm

Depth: 175 mm

Material: Brass

Waste: Yes

Mount Type: Deck

Handle Type: Lever

Minimum Operating Pressure (Bar): 0.1 Bar

Valve/Cartirdge Type: 1/4 Turn Ceramic Disc

WRAS Approved: Yes

WRAS Approval Number: 2204064

TMV2 Approved: No

TMV3 Approved: No

Flow Rate at 0.1 Bar (L/min): 3.0000

Flow Rate at 0.5 Bar (L/min): 16.0000

Flow Rate at 1 Bar (L/min): 22.0000

Flow Rate at 2 Bar (L/min): 31.0000

Flow Rate at 3 Bar (L/min): 38.0000

Tap Holes Required: 1

Tap Spout Projection: 127.0000 mm

Manufacture Guarantee: 20 Years

Guarantee Details: During installation extra care must be taken to avoid damaging the fittings. We provide Manufacture Guarantee against faulty workmanship or materials (excluding serviceable parts), providing they have been installed, cared for and used in accordance with our instructions.
